Overview
The USB Type-C Breakout board is a compact and versatile module designed for USB-C prototyping, testing, and educational applications. It provides easy access to essential USB-C signals through standard 2.54 mm pin headers, making it ideal for breadboard use and custom electronics projects.
This USB Type-C Breakout exposes VBUS (5 V power), GND, USB 2.0 D+ and D− data lines, CC1 and CC2 configuration channels, and SBU1/SBU2 sideband pins. Onboard 5.1 kΩ pull-down resistors on the CC pins ensure proper USB-C sink detection and reliable power negotiation in both plug orientations.
Designed as a USB 2.0-compatible breakout, the board is suitable for Full-Speed and High-Speed USB applications, microcontroller interfacing, and general USB-C experimentation. The SBU and CC pins are also brought out for advanced users who wish to explore custom signaling or USB-C behavior beyond basic power and data.
With a 2-layer PCB, solid ground pours, and a compact footprint, this USB Type-C Breakout offers stable electrical performance while remaining easy to integrate into prototypes and development setups. It is intended for hobbyist, educational, and development use and does not support USB Power Delivery (PD) or USB 3.x SuperSpeed modes.
What You Will Receive (Digital Download)
This product pack will include:
- PCB Gerber File
- Bill of Materials (BOM)
- Pick and Place (CPL)
- Full product datasheet
- Documentation pack (README, License, T&C)
These files can be directly uploaded to PCB manufacturers such as JLCPCB, PCBWay and other manufacturers for fabrication.
Pinout Description
| Pin | Label | Function |
| 1 | VBUS | USB 5V power input |
| 2 | GND | Ground |
| 3 | CC2 | Configuration Channel 2 (with onboard 5.1 kΩ Rd) |
| 4 | SBU1 | Sideband Use 1 |
| 5 | D+ | USB 2.0 Data Positive |
| 6 | D− | USB 2.0 Data Negative |
| 7 | CC1 | Configuration Channel 1 (with onboard 5.1 kΩ Rd) |
| 8 | SBU2 | Sideband Use 2 |
PCB Layout & Dimensions
| Parameter | Value |
| Board Size | 21mm x 14mm |
| Layers | 2 |
| Components Placement | Top layer (Single side) |
| Header Pitch | 2.54 mm |
| USB Connector | USB Type-C Receptacle |
